Paper Tape Collator MP-100
MP-100 Paper Tape Collator – High-Speed Automation for Large-Scale Nail Collation
The MP-100 Paper Tape Collator is a state-of-the-art solution for high-speed collation of nails onto paper tape, designed for industrial-scale nail manufacturing. With advanced automation, it maximizes efficiency and consistency, ensuring seamless integration into high-production environments.
Equipped with a precision nail feeding system, the MP-100 guarantees flawless alignment and secure adhesion of nails onto the paper tape, enhancing the durability and handling of the final product. The machines robust design minimizes operational downtime while ensuring uniform collation quality.
With its exceptional production speed, the MP-100 significantly boosts throughput, making it an ideal choice for manufacturers aiming to meet high-demand requirements. Its intuitive touchscreen control system simplifies operation and adjustments, allowing for quick modifications based on nail specifications.
The MP-100 is a top-tier choice for businesses seeking an automated, high-capacity nail collation solution that ensures efficiency, quality, and cost-effectiveness in paper tape nail production.
| Feature | MP-100 |
|---|---|
| Code | 31-0000 |
| Weight | 3,600 kg |
| Features | Straight steep down rail: 1,560mm length, 28 degrees aligned. Pre Heater: HF Induction preheating system. Tape magazine: Pair of horizontal cartridges provide paper tape. Strip cooling: Blowing ambient air cools down the heated nail. Cutter: Cutting scissors move by a servo motor to make a clear cut. Coating: Spray roller coating with recycling pump and stainless storage tank type. Stacker: 4 index electromagnet type/Conveyor: up to 12 strips per stack. Drying carrousel dries coated strip with a warm air dryer. Stacker: Gripper stack strips onto a conveyor. Conveyor: A dozen of piled-up strips help packing. |
| Nail Diameter Range | 2.5 - 3.77 mm (0.099 - 0.148 inch) |
| Nail Length Range | 45 - 100 mm (1 3/4 - 4 inch) |
| Speed | Up to 1,200 nails/min. |
| Electric Power | 27 kW max, 3P, 210-230 V, 50/60 Hz |
| Nail Angle Range | 33 - 35 degree |
| Nails Per Strip | 20 - 40 pcs |
| Air Consumption | 400 liters/min. |
| Air Supply | 6 bar (87 psi), one 1/2 inch hose |
